High-Performance Multi-Function Antenna for M2M Applications with Cellular, WiFi, and GPS/GNSS Coverage
This multi-function antenna is designed for applications where cost-effectiveness, efficiency, and robustness are crucial, such as vending machines, payment terminals, and other M2M devices. It integrates a 2×2 MIMO function for 2G/3G/4G/5G (698-3800 MHz), a 4×4 MIMO function for 2.4/5 GHz WiFi, and an active GPS/GNSS element, ensuring reliable performance even when mounted on non-metallic surfaces. Available with either a black or white radome, the antenna meets IK10 vandal resistance and IP69K ingress protection standards.
Key Features
- Up to 9 Elements: Includes two isolated high-performance antenna elements covering 617-960/1710-6000 MHz for MIMO/diversity at cellular/LTE frequencies.
- WiFi Support: Up to six optional dual-band elements covering 2.4 & 7.2 GHz for MIMO/diversity WiFi operation.
- High-Performance GPS/GNSS: Optional 26 dB gain LNA with high-quality filtering for unmatched positioning accuracy.
- Non-Metallic Mounting: Performs well even without a metallic ground plane, ideal for non-metallic surface installations.
- Durability: IK10 vandal resistance and IP69K ingress protection for reliable use in harsh environments.
| Specification Category | Details |
|---|---|
| Product Type | Tool accessory |
| Ordering Note | CommScope® non-standard product |
| Application | Cutting blade |
| Cutting Blade Life | 25 cable preparations |
| Cutting Blades Included | 5 |
| Jacket Blades Included | 5 |
| Tool Type | Cutting blade |
| Nominal Size | 1/2 in |
| Wrench Opening | 0 mm | 0 in |
| Material Type | Steel |
| Torque Value | 0 in lb | 0 N-m |
| Height, packed | 127 mm | 5 in |
| Width, packed | 177.8 mm | 7 in |
| Length, packed | 99.06 mm | 3.9 in |
| Packaging quantity | 10 |
| Weight, gross | 0.5 kg | 1.102 lb |
