Supports Extended Ethernet Runs with Shielded Outdoor-Grade Protection
Designed for long-distance Ethernet deployments, this shielded twisted pair cable enables reliable data and PoE transmission up to 259 metres. The cable features a rugged dual-jacketed design with waterproof gel, aluminium/polyester tape shielding, and a tinned copper drain wire, making it suitable for direct burial in outdoor environments. Certified for CM and AWM 600V ratings, it handles both high-performance networking and power transmission safely. Compatible with Cat6 components, it’s ideal for extended PoE applications requiring 2.5 Gbps and up to 100W over longer distances.
Key Features
- Extended Transmission Distance: Supports up to 2.5 Gbps and 100W PoE to 200 m; 10 Mbps and 100W PoE to 259 m.
- Shielded Construction: Includes aluminium/polyester tape shield and 24 AWG drain wire for EMI protection.
- High Voltage Rating: Rated for 600V AWM applications for power and data flexibility.
- Direct Burial Ready: Fully gel-flooded core and dual-jacketed with FRPE for moisture resistance.
- Wide Temperature Range: Operates from -44°C to +80°C for harsh outdoor conditions.
- Universal Compatibility: 22 AWG conductors work with standard Cat6 jacks and RJ45 connectors.
Engineered for challenging outdoor installs, this cable ensures long-range Ethernet and PoE reliability.
| Product Specifications | |
|---|---|
| Conductor Type | Solid bare copper, 22 AWG |
| Pairs | 4 twisted pairs |
| Shielding | Aluminium/polyester tape with 24 AWG drain wire |
| Jacket Material | Dual LSZH FR Polyolefin |
| Outer Diameter | 0.380 in |
| Voltage Rating | 600V AWM |
| Temperature Rating | -44°C to +80°C (operating) |
| Maximum Distance | 259 m at 10 Mbps, 200 m at 2.5 Gbps |
| PoE Support | Class 1 to 8 (up to 100W) |
| Color | Black |
| Put-Up Length | 1,000 feet (305 m) reel |
| Weight | 63 lbs |
