Discover the OMNI-296, a dual-band Omni-Directional Wi-Fi Antenna, catering to 2.4 GHz and 5.0 – 7.2 GHz bands with a 10dBi gain. Ideal for urban and industrial applications, it’s compliant with IEEE 802.11ac/ax/b/g/n standards and ready for 5G with its coverage of the 3.5 GHz CBRS band. The robust, IP65 rated enclosure ensures durability in challenging environments.
The OMNI-296 is a versatile, dual-band Wi-Fi omni-directional antenna from Poynting Antennas, designed to enhance wireless connectivity in both urban and industrial settings. This antenna supports a wide range of frequencies, making it ideal for diverse applications.
Key Features:
- Dual-Band Wi-Fi Support: Operates in the 2.4 GHz and 5.0 to 7.2 GHz frequency bands.
- Compliance with Wireless Standards: Compatible with IEEE 802.11ac/ax/b/g/n standards.
- Medium Gain Antenna: Offers a maximum gain of 10dBi for excellent signal strength and coverage.
- Future-Ready: Covers the 3.5 GHz CBRS band, preparing for future 5G applications.
- Robust Build: The antenna features a vandal and water-resistant enclosure (IP65), suitable for harsh environments.
The OMNI-296 is designed to resolve channel saturation and offers flexibility in Wi-Fi performance. It’s suitable for point-to-point links in noisy, cluttered environments. The antenna’s dual-band capability ensures efficient use of the radio spectrum, providing reliable connections.
Technical Specifications:
| Specification | Details |
|---|---|
| Industry (Application) | Urban & Rural Cellular, Commercial & Industrial |
| Technology | Cellular (LTE/2G/3G/4G/CBRS/5G), Wi-Fi |
| Frequency Band | 2400-2500MHz, 3300-4200MHz, 4900-7200MHz |
| Frequency Range | 2400 – 7200 MHz |
| Gain | 10dBi |
| Directionality | Omni-Directional |
| Mounting Type | Pole Mount, Wall Mount |
| Connectors | N-Type |
| MIMO | SISO |
| Polarisation | Linear Polarised |
| Environmental Rating | IP65 |
| Enclosure Name | Cobra |
| Enclosure Size | Medium |
| Wi-Fi Ports | 1 |
The OMNI-296 is an exceptional choice for enhancing Wi-Fi connectivity in various environments. Its dual-band capability, high gain, and robust design make it a reliable and future-proof solution for any wireless network requirement.
