Industrial LTE Gateway With GNSS and Advanced I/O Functionality
This ultra-compact industrial LTE Cat 4 gateway combines mobile connectivity with serial communication, digital I/Os, GNSS tracking, and advanced industrial protocol support. Designed for remote monitoring and automation, it supports dual SIM failover, GNSS positioning, and a wide power input range, all housed in a rugged DIN/wall-mount aluminium enclosure. It runs on Teltonika's RutOS and supports OpenVPN, Modbus, OPC UA, BACnet, MQTT, DLMS, and more.
Key Features
- Reliable LTE Connectivity: LTE Cat 4 modem with fallback to 3G and 2G, supporting global band options and dual SIM auto-switching for failover.
- Wide Protocol Support: Offers Modbus RTU/TCP, MQTT, OPC UA, DLMS/COSEM, BACnet, DNP3, SNMP, and more—ideal for SCADA and IoT integration.
- Secure VPN Options: Built-in support for OpenVPN, IPsec, GRE, WireGuard, ZeroTier, SSTP, and DMVPN for encrypted remote access.
- Advanced Industrial I/O: Includes 3 digital inputs, 3 digital outputs, 1 analog input, and serial RS232/RS485—all on a 16-pin terminal block.
- Cloud Monitoring Ready: Supports Teltonika RMS, TR-069, SNMP, FOTA, and JSON-RPC for local and remote management.
- Integrated GNSS Receiver: Multi-constellation support for GPS, GLONASS, BeiDou, Galileo, and QZSS with 2.5 m CEP accuracy.
- Compact Rugged Design: Industrial-grade aluminium housing (IP30) with DIN/wall/flat mounting and wide operating temperature of -40 to 75 °C.
- Secure Firewall & Web Filter: Includes DoS protection, port scan prevention, web blacklists/whitelists, VLAN separation, and dynamic firewall rules.
- Low Power Consumption: Runs at under 3.5 W max with reverse polarity and surge protection.
Designed for demanding IIoT and automation environments, this LTE gateway offers powerful remote management, positioning, and protocol translation features.
| Product Specifications | |
|---|---|
| Mobile Connectivity | 4G LTE Cat 4, 3G, 2G fallback; Dual SIM auto-switch |
| Ethernet Port | 1 x 10/100 Mbps (RJ45) |
| Serial Ports | RS232 (TX/RX/RTS/CTS), RS485 (2/4-wire) |
| Digital I/O | 3 x DI, 3 x DO, 1 x Analog Input (0–30 V) |
| VPN Support | OpenVPN, IPsec, GRE, WireGuard, DMVPN, SSTP, ZeroTier |
| Protocols | Modbus, MQTT, OPC UA, DLMS, BACnet, SNMP, DNP3 |
| GNSS | GPS, GLONASS, BeiDou, Galileo, QZSS (2.5 m CEP) |
| Power Input | 9–30 V DC with reverse polarity and surge protection |
| Power Consumption | < 3.5 W (max) |
| Operating Temperature | -40 °C to 75 °C |
| Operating Humidity | 10% to 90% (non-condensing) |
| Enclosure | Aluminium housing, IP30 rated |
| Dimensions | 83 × 25 × 74.2 mm |
| Weight | 165 g |
| Mounting Options | DIN rail, wall, or flat surface (with optional kit) |
| Approvals | CE, UKCA, FCC, IC, CB, RCM, WEEE, EAC |
