Smart Doorbell and Lock kit with Keypad, 2K Video, and Local Storage
This smart entry kit combines the EZVIZ EP3X Pro dual-lens video doorbell with a smart keypad lock and plug-in chime for complete front-door access and surveillance. Featuring a 2K main camera and 1080p downward lens, it delivers clear coverage of both visitors and packages. Built-in 32GB eMMC storage, AI detection, and secure PIN access ensure wire-free, subscription-free protection with flexible entry control.
Key Features
- Dual-Lens Video Monitoring: 2K forward lens and 1080p downward lens provide full visual coverage of people and deliveries.
- Keypad Access Control: Allows secure PIN entry without requiring keys or app unlocking.
- Built-In 32GB eMMC Storage: Offers local storage with no subscription or SD card required.
- AI-Powered Detection: Recognises humans and packages, reducing false alerts from animals or background motion.
- Color Night Vision: Built-in LED enables clear low-light video recording at night.
- Two-Way Audio with Voice Changer: Respond to visitors while masking your voice remotely via the EZVIZ App.
- Wi-Fi Chime with Signal Boost: Plug-in chime extends Wi-Fi range and provides up to 20 adjustable ringtones.
- Tamper Alert and Account Lock: Triggers a siren and push notification if the device is forcibly removed.
- No Subscription Needed: Operates fully using built-in storage and app control—no monthly fees.
- Flexible Power Options: Supports operation via rechargeable battery or 8–24 VAC hardwiring.
With high-resolution video, secure PIN access, and no recurring costs, this kit offers a streamlined solution for modern front-door control and visibility.
| Product Specifications | |
|---|---|
| Model | CS-EP3x Pro + CH1 + Solar Panel |
| Main Camera Resolution | 2K (2048 × 1296) |
| Bottom Camera Resolution | 1080p (1920 × 1080) |
| Field of View | Front: 162° / Bottom: 155° |
| Night Vision | Color night vision up to 6 m |
| AI Detection | Human and package detection with custom zones |
| Access Methods | Keypad PIN access, EZVIZ App, Two-way talk |
| Storage | Built-in 32GB eMMC (local), EZVIZ CloudPlay optional |
| Battery Capacity | 5,200 mAh rechargeable lithium |
| Power Options | Solar panel, battery, or 8–24 VAC wired |
| Chime Power | 100–240 V AC (plug-in) |
| Audio Features | Two-way talk, voice changer, tamper siren |
| Connectivity | Wi-Fi 2.4 GHz (802.11 b/g/n), dual antenna |
| Weatherproof Rating | IP65 (doorbell and solar panel) |
| Operating Temperature | -20°C to 50°C |
| Doorbell Dimensions | 166 × 50 × 31 mm |
| Chime Dimensions | 101 × 64 × 32 mm |
| Solar Panel Dimensions | 126 × 56 × 44 mm |
| Certifications | CE, REACH, WEEE, RoHS |
